Quinn Therm QW Cavity Wall PIR 1200mm x 450mm x 60mm

Quinn Therm QW Cavity Wall PIR Insulation is a high performance, fibre free board, with a rigid thermoset insulation core and faced on both sides with a low emissivity composite foil facing, for use in partial fill cavity wall applications.

The low emissivity foil facings increases the thermal resistance of the residual cavity and reducing the overall U-value of the wall.

The good dimensional tolerances of the QW Cavity Wall PIR Insulation board enabling it to be tightly butted to form a continuous layer of insulation.

Specification

• QW-Cavity Wall board sizes are co-ordinated with standard wall tie spacings
• Tongue and groove edging for continuity of insulation across joints
• Zero ozone depletion potential (zero ODP) and low global warming potential (GWP)
• Achieves an A+ rating when compared to the BRE Green Guide

Performance & Properties

Board size (mm)450mm x 1200mm

Thickness (mm)40mm – 80mm

EdgeButt, tongue and groove

Thermal Conductivity (λ)0.022mk

FacersLow emissivity foil facers

Core water vapour resistivity≅300MNs/gm

Compressive strength>150kPa

***THIS ITEM IS FOR COLLECTION OR NEXT DAY DELIVERY WITHIN 8 MILES OF PL5 3LR ONLY***

IF DELIVERY IS REQUIRED OUTSIDE THIS AREA PLEASE CONTACT US ON 01752 751136
